CHRISTMAS CAROLS The Editor stopped me. "Waddilove," he slurred. "Christmas is coming. Do something."

After spending a week or so racking my brains trying to think of an original Christmas program I came up with Christmas Carol. It simply wishes everyone a Merry Christmas to the accompaniment of a few festive tunes.

You may be wondering where the originality is in that. Well, it's not what it does, it's how it does it.

The program demonstrates the use of interrupts by playing carols while text is printed in different directions and with various degrees of rotation.

One of the most advanced features of the Electron, and the BBC Micro as well, is the extensive use of interrupts to control many of the background operating system tasks.

An interrupt is a signal sent to the microprocessor telling it to stop what it is doing and switch its attention to something else.

When it has finished this task it returns to whatever it was doing and carries on as if nothing had happened.

These background tasks include updating the clock, used by the pseudo variable TIME, processing ENVELOPEs and maintaining the many input and output buffers and queues.

Interrupts give the impression that the Electron is capable of doing more than one thing at a time by repeatedly switching rapidly between tasks.

Interrupts must not have any effect on the interrupted program. If any of the processor's registers or flags are altered by the interrupt routine, then it will get in a terrible muddle when it returns, probably with disastrous consequences.

Acorn have thoughtfully provided the user with an easy to use, pre-packaged interrupt facility. Every ten milliseconds an interrupt is generated by one of the timers inside the ULA to transfer program control to routines to deal with the background work.

In the process of carrying out this background work a number of events may be generated, such as the interval timer crossing zero. An event handling routine can be written by the user to which control is passed when the appropriate even has been detected by the Operating System.

The Operating System detects all events but ignores them if they have not been enabled with a *FX14 command. If an event has been enabled then program execution indirects via the event vector at &220. (See Page 242 of the User Guide.)

The machine code routine in Xmas Carol is called fifty times a second, coincident with the start of certical synchronisation of the screen display, by setting the event vector to point to the start of the code, and enabling it with *FX 14,4.

When the code is called the registers and flags are saved. As only one event has been enabled there is no need to check that it is the right one.

First it is necessary to see if there is enough space in the sound buffer for the next note, otherwise the program would grind to a halt when it was full.

If there is not enough room, the regsiters are restored and the routine ends.

If there is enough room, then the next note and its length are read from the data stored at page &A and placed in the parameter block at &71. OSWORD is called to insert the note into the sound buffer.

A check is made to see if the pointer is at the last note. If it is, then it is reset to the start again. The registers are restored and the routine ends.

All this happens while the Electron is busy drawing the message on screen, giving the appearance of doing two things at once.

The print routine works by printing the letter at the bottom left hand corner of the screen, and looking at the dot pattern produced.

You can't see it as it is printed in colour 3 which is set to black, the same as the background.

By using some elementary trigonometry the dot pattern can be rotated and drawn at any position on the screen. A point I%, J% when rotated through an angle theta becomes:


An allowance has to be made for the odd shaped pixels in Mode 5 but it is fairly straightforward.

To print text round in a circle you just move to a point on the circumference x%, y% which is radius*SIN(theta), radius*COS(theta). To make the text stand outwards the angle of rotation is -theta.

The machine code is placed at &900 and the data for the carols at &A00, which are buffers used by the cassette system.

It is safe to type in and run programs while the carols are playing, but loading or saving a program may corrupt the code so it is best to disable the routine with *FX13,4.

Don't just use the program as it is. Try experiemtning with different tunes. (Lines 220, 230 and 790 must be set to the number of items in the DATA statement, 254 maximum.)

Alter the messages printed and see what happens if the size of the letters is changed.

Will it run in Mode 1? Try it and see. Alter it if necessary.

I%,J% Used as loop counters
a$,b$ Messages to be printed
theta Angle of letter in radians
angle Angle of letter in radians
x%, y% Position of letter
X%, Y% Position of letter
size Size of letter
sin, cos Work out SIN and COS function to save time
letter$ Letter to be printed
pointer Pointer to next note
sound Parameter block for OSWORD call
PROCstore_data Disable start of screen synchronisation display event. Switch off ADC channels. Read and store data for tunes. Define function keys.
PROCassemble Assemble machine code routine to play carols. Set event vector to point to code. Enable event
PROCletters Print the message
PROCprint Print a character at a given angle and position


A game of strategy by John Woollard

CHRISTMAS BOX CHRISTMAS BOX is a game of strategy designed to while away a pleasant time after a substantial Christmas dinner.

The rules are simple: Two players take turns to enter a Christmas Box into the grid by pressing a letter key from A to F.

The piles of presents build up to the top, but no further, to the accompaniment of We Wish You A Merry Christmas.

Q cuts the music, S starts it again.

The winner is the first person to get four of their presents in a straight line - vertically, horizontally or diagonally.

If you don't want to type the whole thing by hand then send off for this month's tape. If you want to learn some new techniques to aid your programming then read on.

And if you want to write a program with a structured format so that it can be changed to your requirements then start key tapping.

The program has been written so that another programmer can easily see how it works and therefore be able to change it to suit themselves.

The first nineteen lines do everything. They form the main control module.

The lines call procedures or functions in a sequence that creates the effect seen on the screen. There is a single REPEAT UNTIL loop which continues until one or other of the players has won.

After the end message has been displayed the program automatically starts again.

The program was designed to be flexible in its use. The tune can be changed by changing the values in the DATA statements of lines 1760 and 1170. The shape of the Christmas Boxes can be changed entirely by altering lines 1690 to 1720.

The shape of moving sleight is set in line 470.

Obviously, all text can be changed by changing the appropriate PROCPrint calls.

It is most important that these statements are entered accurately as mistakes may not appear as syntax errors but as spurious errors whose source is hard to determine.

Lines 1730, 1740 and 1750 contain the winning combinations. Lines 1760 and 1770 contain the notes of the tune.

Name$(1) Contains the names of the two players
grid%(6,5) Contains a value for each position on the display. Those unique values are used to determine if a player has a winning combination of Christmas Boxes
win%(40) Contains the totals of the 39 winning positions
pitch%(54) and
Contain the pitch and duration of the 54 notes of the tune that plays during the game
win% A flag that starts at zero and becomes positive to show that a player has achieved a winning position
person% Either 1 or 0 and indicates which player's turn it is
k, k1, k2 ... General purpose counters that do not cross procedure boundaries
shape$ Contains a string that produces the moving sleigh at the top of the screen
T% Used to count through each note of the tune and determine the position of the sleigh on the screen
get% Stores the value of the player's choice of letter
I and inkey% Temporary stores of the result of an INKEY statement
Procedures & Functions
PROCtitle Sets up the initial screen with a display of grid and title
PROCinitialisation Dimensions all variables used, reads the DATA statements and assembles a machine code routine that creates double height characters. (That routine was described and explained in the July edition of Electron User) The initialisation procedure also contains several *FX calls which are useful in many programs. *FX 16,0 disables the analogue/digital sampling. This is an advantage only if the Plus 1 is fitted. *FX229,1 disables the action of ESC. It may be useful to set it to *FX229,0 while debugging is carried out. The other *FX calls are documented in the Electron User Guide.
PROCnamein Allows the two players to enter their names and wishes them luck
PROCdisplay Creates an empty grid for the players to enter their Christmas Boxes
PROCplay Waits for the player to make a choice and enters the Christmas Box
FNcheck Checks to discover if that move was a winning move. If it was then win% is set to a positive value
PROCendmessage Displays its Christmas Greetings when the loop ends
PROCget Waits for a letter key to be pressed between A and F. However, if Q is pressed the sound is quietened, if S is pressed then it is enabled. The procedure uses *FX210,0 to enable all sound output and *FX210,1 to disable all sound output
FNname An input routine that prints the inputted characters in double height to a maximum length of twelve characters
PROCPrint (x,y,COL,a$) Utilities the machine code routine created in the initialisation procedure so that whole strings can be printed in double height
PROCshape (shape%,colour%,
Displays a coloured shape determined by the value of shape% and colour% at a position on the screen determined by xcoord% and ycoord%


CHRISTMAS SNAP CHRISTMAS SNAP is Phil Tayler's Electron version of the old card game for young children.

A multicoloured Christmas object, such as a tree, appears on the left of the screen and a series of similar objects appears one after the other on the right.

Your job is to tell the Electron when the colours of the objects match exactly. Only you don't say "Snap" - you press the Space bar.

If you're wrong you'll get a short beep. If you're right... well, play the game and find out.

Happy Christmas. Happy Christmas. Snap!

count Used to determine the point at which we jump out of the REPEAT...UNTIL loop. Initially count is FALSE, but if a correct match is made, it becomes TRUE.
X% and Y% Used in PROCchristmas_tree and so on to set up the text window
B to H random% Used for the random colouring of the right-hand pictures. Actually, they are not truly random, as a variable random% becaomes B and then the other variables take their values in order from this one
timeallowed The variable set during the initialisation to decide how long should be allowed to the child to respond
G Also used as a keyboard variable using G=GET
note Used as a counter in the loops playing the carols. A, P and D (as appropriate) are used to read amplitude, pitch and duration
PROCinstructions Sets up the introductory and instruction screens in Mode 6
PROCrandomcolour Gives values to the variables B-H (used in PROC's to set up the pictures). It decides a random value for B, and the others take their values for that
These set up a text window on the left of the screen, then the variables A-H are given their correct values, then it jumps into the corresponding general PROC (for example, PROCchristmas_tree).
These accept the randomly generated values for the variables B-H set up a text window on the right of the screen, and then draw the corresponding picture
PROCtune uses a random feature to decide which of the four carols is to be played. It then calls up the appropriate PROC.


MOUSER MOUSER was written to help children practise their skills with compass directions.

A mouse is hidden on a 12 x 12 grid labelled with the coordinates A1-L12. Your task is to send your cat to find the mouse - but you only have five goes.

Each time you make a mistake the micro will tell you a compass direction to take.

You must tell the micro the coordinate of the square you wish to search. Incorrect coordinates will not be accepted.

I would recommend you change line 100 to *FX229,1 to disable ESCAPE when you are sure that the program has been fully debugged.

If you want to make the game easier by having more turns, just change the value of S% in lines 80, 1200 and 1660 to give more than five goes.

PROCinstructions Gives instructons
PROCplace Hides the mouse
PROCguess Guess location
PROClose Lose game
PROCmouse Draws mouse
PROCcat Draws cat
PROCman Draws man
PROCmove Chooses direction you can move
PROCwin Find mouse
PROCsouth Go South
PROCnorth Go North


SILLY SANTA Santa has a bug in his Operating System this year. He has delivered sacks of presents to the six people in Disc Drive, but put them in the wrong houses.

You, the Electron Elf, must sort out the muddle before everyone wakes up on Christmas morning.

You do this by moving from house to house collecting or dropping sacks. You can carry up to three sacks at a time.

If you succeed, then you get another go, but the time you are allowed is the time you took in your first go.

If you fail, you are given 20 seconds longer for your next turn. Appropriate tunes are played for success or failure and a record is kept of the fastest time.

The first part of the program uses a series of PROCcircles to produce a picture. The game itself follows and instructions are included within the program.

T% Time allowed to complete task
M% Best time so far
z% Number of present house
newz% Number of house you hope to visit
A$(N) Initial sack numbers
B$ Numbers 123456
C$ Shuffled B$
carry$ Sacks being carried at present
take$ Sack you hope to take
leave$ Sack you hope to drop
drop$ Sack you have dropped
PROCcredits Prints title
PROCcircle (X,Y,R,C) Used for starting picture. Draws circle centred at (X,Y), radius R in colour C
PROCinstruct Prints instruction on screen
PROCchose Decides which sack is randomly left at which house
PROCsetup Sets up text and graphics windows, selects colours, defines characters and some variables
PROChouse(X,Y) Draws houses at (X,Y)
PROCsanta(X,Y,C) Draws a man in each house at position (X,Y) and logical colour C
PROCsack Positions sacks in the correct places
PROCdecide The playing part of the game in which you make decisions
PROCremove Deals with the removal of sacks from the houses
PROCdrop Deals with leaving sacks at houses
PROCfail Displays fail message
PROCsuccess Displays success message
PROCgoodtune Plays a happy Christmas song
PROCbadtune Plays a bad Christmas song
PROChall Prints the fastest time
